Print Head/Consumables |
|
| Number of Nozzles | Total 1,280 nozzles |
| Ink Cartridges (Type/Colours) | PG-745S (Pigment Ink/Black), CL-746S (Dye-Based Ink/Colour) |
| [Optional: PG-745, CL-746 / PG-745XL, CL-746XL] | |
| Maximum Print Resolution | 4,800 (horizontal)*1 x 600 (vertical) dpi |
| Print Speed*2 (Approx.) | |
| Based on ISO/IEC 24734 | |
| Document (ESAT/Simplex) | 8 / 4 ipm (mono/colour) |
| Print Width | Up to 203.2 mm (8″) |
| Recommended Printing Area | Top margin: 31.6 mm |
| Bottom margin: 29.2 mm |
| Scan*3 | |
|
Scanner Type |
Flatbed (Platen) |
| Scanner Technology | Contact Image Sensor (CIS) |
| Optical Resolution*4 | 600 x 1,200 dpi |
| Scanning Bit Depth (Input/Output) | |
| Greyscale | 16 bit / 8 bit |
| Colour | 48 bit / 24 bit (RGB each 16 bit / 8 bit) |
| Maximum Document Size | |
| Flatbed | A4, LTR (216 x 297 mm) |
| Copy | |
|
Copy Speed*5 (Approx.) |
|
| Based on ISO/IEC 24734 | |
| Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex) | 31 sec / 1.6 ipm |
| Maximum Copies | 21 pages |
| Maximum Document Size | A4, LTR |
| Paper Handling | |
|
Print Margin |
|
| Bordered Printing | LTR/LGL: |
| Top margin: 3 mm, Bottom margin: 16.7 mm | |
| Left margin: 6.4 mm, Right margin: 6.3 mm | |
| Others: | |
| Top margin: 3 mm, Bottom margin: 16.7 mm | |
| Left/Right margin: 3.4 mm | |
| Supported Media | |
| Rear Tray | Plain Paper (64 – 105 g/m²) |
| High Resolution Paper (HR-101N) | |
| Photo Paper Plus Glossy II (PP-201, PP-208) | |
| Envelope | |
| Paper Size | |
| Rear Tray | A4, A5, B5, LTR, LGL, Envelope (COM10, DL), 4 x 6″, 5 x 7″ |
| [Custom Size] | |
| Width: 101.6 – 215.9 mm | |
| Length: 152.4 – 676 mm | |
| *F4 is possible via custom settings. | |
| Maximum Capacity | |
| Rear Tray | Plain Paper, 64 g/m² (A4, A5, B5, LTR, ): 60 |
| Photo Paper Plus Glossy II (PP-201, PP-208, 4 x 6″): 20 | |
| Envelope (COM10, DL): 5 | |
| Paper Weight | |
| Rear Tray | Plain Paper: 64 – 105 g/m² |
| Canon Paper: Approx. 275 g/m² (Max.) | |
| (Photo Paper Plus Glossy II, PP-201) |
| System Requirements | |
|
OS System Compatibility*6 |
Windows 8 / 7 / Windows Vista / Windows XP |
| macOS X 10.7.5 or later | |
| General Specifications | |
|
Interface |
USB 2.0 |
| Operating Environment*7 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*8 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Power Requirements | AC 100 – 240 V, 50/60 Hz |
| Power Consumption (Approx.) | |
| OFF | 0.4 W |
| Standby | 1 W |
| Operation*9 | 9 W |
| Dimensions (W x D x H) | |
| Factory Configuration | 426 x 306 x 145 mm |
| Weight | 3.5 kg |
| Page Yield*10 | |
|
Plain Paper |
A4 Colour Documents*11: |
| PG-745S / CL-746S: 100 | |
| Optional: | |
| PG-745/CL-746: 180 | |
| PG-745XL/CL-746XL: 300 |
